Garden Drainage Pump Station – Twin 6m Head Pump System – Basement & Drainage Solutions
£1,008.00
Garden Drainage pump station BD-300ST
Garden drainage pump station BD-300ST is designed to help deal with wet and soggy garden areas that are also prone to flood conditions, particularly during or after periods of heavy rainfall,
Background Information:
Garden Areas:
Our desire to enjoy our gardens is a great thing.
Therefore, having a garden that does not suffer from flooding is essential.
However, many new properties built on clay-based soil will suffer poor natural drainage.
Clay-based soils tend not to allow free draining of rainwater, and soggy lawns become a nuisance.
A proven solution is excavating the ground and installing land drainage pipework that links to a drainage pump system. The pump system can then transfer the collected water away from the affected area.
Available Solutions:
Install surface drainage channels/land drainage pipework in the affected areas so that the water has an immediate place to go.
Where necessary, link the channels to the drainage pump station BD-300ST. or one of an alternative chamber size.
The pump system automatically transfers the collected excess water to a final discharge point.
A suitable final discharge point may be the property’s surface water drainage system, a watercourse, or a purpose-built soakaway.
As a result, the property and surrounding areas will be less likely to flood when using a planned surface water drainage system.
Selecting The Most Suitable Pump Station:
The total surface area to be protected will govern the drainage system required to do the job. Therefore, the larger the surface area, the larger the chamber volume for collecting the water.
Chamber sizes are available, ranging from 190 litres up to 1000 litres.
For example, drainage pump station BD-600ST has a 600-litre capacity pump chamber.
Product Quality Standard:
Drainage water pump station BD-300ST meets the highest British Standards relevant to our industry, such as BS EN 12050-1:2001 Wastewater lifting plants for buildings and sites, BS EN 12056-4:2000 Gravity drainage systems inside, and BS EN 752-6:1998 Drain and sewer systems outside buildings.
BD-300ST Storm/ Surface Water Pumping Station Package:
Automatic submersible pump
610mm x 1000mm poly pump chamber with re-enforced ribs and a 10-year warranty
Heavy Duty rated 450m dia lockable lid cover
Non-return valves to prevent water recycling and excessive pump use.
Lifting chains and D-link so that lifting the pump out of the chamber is made easy.
Internal PVC discharge pipework kit because it simplifies the installation work at the site.
110mm Seal for incoming Pipe
63mm MDPE adaptor because it facilitates the connection to the outgoing pipework
24 months warranty
Price includes VAT and delivery to UK mainland Garden Drainage Pump Station – Twin 6m Head Pump System – Basement & Drainage Solutions
Specification: Garden Drainage Pump Station – Twin 6m Head Pump System – Basement & Drainage Solutions
| Store Name | |
|---|---|
| Brand | Basement & Drainage Solutions |
| Condition | New |
| Availability | In Stock |
