Rockford Fosgate 2014+ Harley-Davidson Dual 10″ Saddlebag Subwoofer Kit – Rick Rak
£0.20
Plug-and-Play Design: Designed to work right out of the box. The included wiring and cutting template make for easy installation, all to ensure less time in the garage and more time out riding.
• Full Throttle Bass Output: Finally, bass for your bike. The dual 10” subwoofers and enclosures were purpose built for the motorcycle environment and deliver that on-road audio experience you’ve been waiting for, even at freeway speeds.
• Flexible Bass System: Sound when you want it, space when you need it. This patent pending design allows you to remove one or both subwoofers easily with no tools. So, if you need your bags for a long ride, this flexible system allows for just that.
• Rockford Motorcycle Ecosystem: Everything was purpose-built to seamlessly work with your existing Rockford Fosgate Harley-Davidson system. With a few simple connections this dual bass system integrates flawlessly.
• Refer to our COMPATIBILITY chart to verify system requirements and fitment before purchasing.
Plug and Play design for easy installation
Play all day, easy to integrate, and keep music playing for extended lengths of time
Purpose built for 2014+ Harley-Davidson® Street Glide® and 2015+ Road Glide® (see compatibility tab)
Designed for use with 2014+ Factory Harley-Davidson® Hardshell Bags
Comes loaded with M1D2-10B Element Ready™ Subwoofer (No RGB LED Color Optix)
M5-800X4: 800 Watt 4-Channel IPX6 Amplifier
Dual air space keeps TMS saddlebag speakers separate from subwoofers
No fasteners needed to keep enclosures in place
Includes sealing plug if enclosures need to be removed
Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
Proprietary testing using RATS (Rockford Automated Testing System)
Klippel Verified certification program delivers the best possible loudspeakers
IPX6 Rated
2-Year Warranty
Specs:
Woofer Qty
2
Woofer Size
10″
Woofer Series
M1D2-10B
Nominal Impedance
4Ω
(2Ω DVC wired to create 4Ω bridged amp load)
Power Handling
300 Watts RMS
1200 Watts Peak
Enclosure Type
Sealed
Enclosure Material
Rotomolded HDPE
Speaker Connector
2-pin Deutsch™/Amphenol™
Frequency Response
20 Hz – 750 Hz
Amplifier Type
Class-AD
Total Power
800 Watts
Grille/Trim Ring Included
Yes
Mounting Hardware
Yes
Included In The Box
(2) M1D2-10B subwoofers
(2) Subwoofer enclosures
(1) M5-800X4 amplifier
(1) Wiring kit
(2) Cutting templates
(1) Amp mounting plate
(1) 1315-75758-01 AP Pack (details below)
(12) Nylon zip ties 8 in
(8) Phillips screws M3 x 0.5 x 12 mm
(1) Hole saw OD 45 mm
(4) Washers OD 9 x ID 3.2 x T0.8
(4) Hex screws 3/16 in, 5/16-18 thread, 1.25 in
(4) Clip 5/16-18 thread
(2) Screw M3 x 0.5, 5 mm
(8) Screw thread cutting ST3.0, 6 mm
(2) Nylon plug ID 0.75 in
(2) Hex nut M3 x 0.5
(8) Phillips screw #8 x 0.75 in.
(1) Hex wrench 3/16 in
(2) Alcohol wipe
Compatibility
This subwoofer system is designed to interface only with the below aftermarket audio kits and compatible Harley-Davidson® motorcycles. If your existing audio system and motorcycle are not listed below, it is not compatible.
Kit only compatible with standard sized Harley-Davidson® ABS plastic bags. Not compatible with stretched or early generation fiberglass bags. Not compatible with factory equipped amplifier or bulkhead wiring harness in saddlebag. If equipped with Tour-Pak, it must be removed prior to removing subwoofer enclosure. Kit requires factory Harley-Davidson® radio to be flashed (likely already done if below kit installed).
Required Audio System
AUDIO SYSTEM
GENERATION
DESCRIPTION
HD14RGSG-STAGE2
Gen-2
2014+ Harley-Davidson® Road Glide® & Street Glide® 2-Speaker & Amp Kit
HD14RGSG-STAGE3
Gen-2
2014+ Harley-Davidson® Road Glide® & Street Glide® 4-Speaker & Amp Kit
HD14U-STAGE2
Gen-2
2014+ Harley-Davidson® Road Glide® Ultra & Electra Glide® Ultra Classic® 4-Speaker & Amp Kit
HD14U-STAGE3
Gen-2
2014+ Harley-Davidson® Road Glide® Ultra & Electra Glide® Ultra Classic® 6-Speaker & Amp Kit
HD14-TKIT
Gen-1
Power Harley-Davidson® Street Glide® (2014+) & Road Glide® (2015+) Front Audio Kit.
Compatible Harley-Davidson® Motorcycles
YEAR
MAKE
CHASSIS
MODEL
FAIRING
2014–current
Harley-Davidson®
FLHTCU
Electra Glide® Ultra Classic®1
Bat Wing
2014–current
Harley-Davidson®
FLHTK
Electra Glide® Ultra Limited1
Bat Wing
2017–current
Harley-Davidson®
FLHTKL
Electra Glide® Ultra Limited Low1
Bat Wing
2015-current
Harley-Davidson®
FLTRX
Road Glide®
Shark Nose
2015-current
Harley-Davidson®
FLTRXS
Road Glide® Special2
Shark Nose
2015–current
Harley-Davidson®
FLTRU
Road Glide® Ultra1
Shark
Specification: Rockford Fosgate 2014+ Harley-Davidson Dual 10″ Saddlebag Subwoofer Kit – Rick Rak
| Store Name | |
|---|---|
| Brand | Rickrak |
| Condition | New |
| Availability | In Stock |
